SmolVLA 模型

"task": "Pick and place the object."

#!/usr/bin/env python3
"""SmolVLA benchmark script for amd64 desktop with CUDA GPU.

What this script does:
1) Verifies CPU architecture and CUDA device.
2) Loads local SmolVLA checkpoint with local VLM/tokenizer path.
3) Builds a fixed image observation.
4) Runs warmup + benchmark loops.
5) Reports latency percentiles and throughput.

Example:
  python test_smolvla_rtx4090.py \
    --model-path ./smolvla_base \
    --vlm-path ./SmolVLM2-500M-Video-Instruct \
    --image-path ./smolvla_base_test.png \
    --warmup 20 \
    --iters 200
"""

from __future__ import annotations

import argparse
import contextlib
import io
import importlib
import json
import os
import platform
import shutil
import statistics
import tempfile
import time
import warnings
from pathlib import Path
from typing import Any, Dict, List, Optional, Tuple

import torch
from PIL import Image


def load_json(path: Path) -> Dict[str, Any]:
    with path.open("r", encoding="utf-8") as f:
        return json.load(f)


def parse_image_shape(config: Dict[str, Any]) -> Tuple[int, int, int]:
    for _, feature in config.get("input_features", {}).items():
        if feature.get("type") == "VISUAL":
            shape = feature.get("shape", [3, 256, 256])
            if len(shape) != 3:
                raise ValueError(f"Unexpected VISUAL shape: {shape}")
            return int(shape[0]), int(shape[1]), int(shape[2])
    return 3, 256, 256


def parse_state_dim(config: Dict[str, Any]) -> int:
    for _, feature in config.get("input_features", {}).items():
        if feature.get("type") == "STATE":
            shape = feature.get("shape", [6])
            if len(shape) != 1:
                raise ValueError(f"Unexpected STATE shape: {shape}")
            return int(shape[0])
    return 6


def count_cameras(config: Dict[str, Any]) -> int:
    n = 0
    for _, feature in config.get("input_features", {}).items():
        if feature.get("type") == "VISUAL":
            n += 1
    return max(1, n)


def load_image_chw_uint8(image_path: Path, h: int, w: int) -> torch.Tensor:
    with Image.open(image_path) as img:
        rgb = img.convert("RGB")
        resized = rgb.resize((w, h), Image.BILINEAR)
        # Use writable bytearray buffer to avoid non-writable buffer warning.
        data = torch.ByteTensor(bytearray(resized.tobytes())).view(h, w, 3)
        return data.permute(2, 0, 1).contiguous()


def build_observation(config: Dict[str, Any], image_path: Path) -> Dict[str, Any]:
    c, h, w = parse_image_shape(config)
    if c != 3:
        raise ValueError(f"Only 3-channel image is supported now, got {c}")

    state_dim = parse_state_dim(config)
    cam_count = count_cameras(config)

    img = load_image_chw_uint8(image_path, h, w)

    obs: Dict[str, Any] = {
        "observation.state": torch.zeros(state_dim, dtype=torch.float32),
        "task": "Pick the red block and place it in the blue region",
    }
    for i in range(1, cam_count + 1):
        obs[f"observation.images.camera{i}"] = img.clone()
    return obs


def create_localized_model_view(model_path: Path, vlm_path: Path) -> Path:
    temp_dir = Path(tempfile.mkdtemp(prefix="smolvla_rtx4090_"))

    for item in model_path.iterdir():
        dst = temp_dir / item.name
        if item.is_file() and item.name.endswith(".json"):
            continue
        try:
            os.symlink(item, dst)
        except OSError:
            if item.is_dir():
                shutil.copytree(item, dst)
            else:
                shutil.copy2(item, dst)

    config = load_json(model_path / "config.json")
    config["vlm_model_name"] = str(vlm_path)
    with (temp_dir / "config.json").open("w", encoding="utf-8") as f:
        json.dump(config, f, ensure_ascii=False, indent=2)

    preproc_path = model_path / "policy_preprocessor.json"
    if preproc_path.exists():
        preproc = load_json(preproc_path)
        for step in preproc.get("steps", []):
            if step.get("registry_name") == "tokenizer_processor":
                step.setdefault("config", {})["tokenizer_name"] = str(vlm_path)
        with (temp_dir / "policy_preprocessor.json").open("w", encoding="utf-8") as f:
            json.dump(preproc, f, ensure_ascii=False, indent=2)

    for name in ["configuration.json", "policy_postprocessor.json", "README.md"]:
        src = model_path / name
        if src.exists() and not (temp_dir / name).exists():
            shutil.copy2(src, temp_dir / name)

    return temp_dir


def sanitize_batch_for_select_action(batch: Dict[str, Any], device: torch.device) -> Dict[str, Any]:
    fixed = dict(batch)
    for key, value in list(fixed.items()):
        if not isinstance(value, torch.Tensor):
            continue
        if not key.startswith(("observation.images.camera", "observation.image")):
            continue

        t = value.to(device)
        if t.ndim == 3:
            t = t.unsqueeze(0)
        if t.dtype == torch.uint8:
            t = t.float().div(255.0)
        elif not t.is_floating_point():
            t = t.float()
        fixed[key] = t

    return fixed


def flatten_action_to_list(action: Any) -> List[float]:
    if isinstance(action, dict):
        if "action" in action:
            action = action["action"]
        else:
            for value in action.values():
                if isinstance(value, torch.Tensor):
                    action = value
                    break
    if not isinstance(action, torch.Tensor):
        return []
    return [float(x) for x in action.detach().float().reshape(-1).cpu().tolist()]


def percentile(sorted_vals: List[float], q: float) -> float:
    if not sorted_vals:
        return 0.0
    if q <= 0:
        return sorted_vals[0]
    if q >= 100:
        return sorted_vals[-1]
    idx = int(round((q / 100.0) * (len(sorted_vals) - 1)))
    return sorted_vals[max(0, min(len(sorted_vals) - 1, idx))]


def _pick_timed_modules(policy: Any) -> List[Tuple[str, str, Any]]:
    """Pick coarse modules for phase timing.

    Returns tuples: (bucket, module_name, module)
    bucket in {"vlm", "smolvla"}
    """
    picks: List[Tuple[str, str, Any]] = []
    seen = set()

    for name, module in policy.named_modules():
        if not name:
            continue
        depth = name.count(".")
        if depth > 3:
            continue

        lower = name.lower()
        bucket = None
        if any(k in lower for k in ("vlm", "vision", "language", "text_model", "vision_model")):
            bucket = "vlm"
        elif any(k in lower for k in ("action", "expert", "decoder", "head", "state_proj")):
            bucket = "smolvla"

        if bucket is None:
            continue
        key = (bucket, name)
        if key in seen:
            continue
        seen.add(key)
        picks.append((bucket, name, module))

    # Keep only a small set of coarse modules to reduce nested double counting.
    picks.sort(key=lambda x: (x[0], x[1].count("."), len(x[1])))
    trimmed: List[Tuple[str, str, Any]] = []
    bucket_count = {"vlm": 0, "smolvla": 0}
    for bucket, name, module in picks:
        if bucket_count[bucket] >= 4:
            continue
        trimmed.append((bucket, name, module))
        bucket_count[bucket] += 1
    return trimmed


def _find_primary_vlm_module(policy: Any) -> Optional[Tuple[str, Any]]:
    # 优先找最靠近根节点的 VLM 子模块，便于稳定拆分主干耗时。
    candidates: List[Tuple[int, int, str, Any]] = []
    for name, module in policy.named_modules():
        if not name:
            continue
        lower = name.lower()
        if "vlm" in lower or "vision_language" in lower or "smolvlm" in lower:
            candidates.append((name.count("."), len(name), name, module))
    if not candidates:
        return None
    candidates.sort(key=lambda x: (x[0], x[1]))
    _, _, name, module = candidates[0]
    return name, module


def measure_phase_breakdown(
    policy: Any,
    batch: Dict[str, Any],
    device: torch.device,
    use_autocast: bool,
    autocast_dtype: torch.dtype,
) -> Dict[str, Any]:
    """Approximate phase timing breakdown using module hooks + CUDA events.

    Note: values are approximate and may include overlap due to nested modules.
    """
    if device.type != "cuda":
        return {
            "enabled": False,
            "reason": "phase breakdown requires CUDA events",
        }

    # Strategy A (preferred): directly time the primary VLM module forward,
    # then estimate SmolVLA head by subtraction from select_action total.
    primary_vlm = _find_primary_vlm_module(policy)
    if primary_vlm is not None:
        vlm_name, vlm_module = primary_vlm
        vlm_times: List[float] = []

        def _vlm_pre(_module, _inputs):
            start = torch.cuda.Event(enable_timing=True)
            start.record()
            _module.__dict__["_vlm_timer_start"] = start

        def _vlm_post(_module, _inputs, _output):
            start = _module.__dict__.pop("_vlm_timer_start", None)
            if start is None:
                return
            end = torch.cuda.Event(enable_timing=True)
            end.record()
            _module.__dict__["_vlm_timer_end"] = end
            _module.__dict__["_vlm_timer_pair"] = (start, end)

        h1 = vlm_module.register_forward_pre_hook(_vlm_pre)
        h2 = vlm_module.register_forward_hook(_vlm_post)

        t0 = time.perf_counter()
        with torch.inference_mode():
            if use_autocast:
                with torch.autocast(device_type="cuda", dtype=autocast_dtype):
                    _ = policy.select_action(batch)
            else:
                _ = policy.select_action(batch)
        torch.cuda.synchronize(device)
        t1 = time.perf_counter()

        pair = vlm_module.__dict__.pop("_vlm_timer_pair", None)
        h1.remove()
        h2.remove()

        if pair is not None:
            start, end = pair
            vlm_ms = float(start.elapsed_time(end))
            total_ms = (t1 - t0) * 1000.0
            head_ms = max(0.0, total_ms - vlm_ms)
            return {
                "enabled": True,
                "method": "primary_vlm_subtract",
                "note": "approximate, head is computed as total-vlm",
                "primary_vlm_module": vlm_name,
                "select_total_ms": total_ms,
                "smolvlm2_ms": vlm_ms,
                "smolvla_head_ms": head_ms,
                "timed_modules": [[vlm_name, vlm_ms]],
            }

    # Strategy B (fallback): coarse module hooks by name heuristics.
    picks = _pick_timed_modules(policy)
    if not picks:
        return {
            "enabled": False,
            "reason": "no matched modules for phase hooks",
        }

    records: List[Tuple[str, str, torch.cuda.Event, torch.cuda.Event]] = []
    handles = []

    def make_pre(bucket: str, name: str):
        def _pre(_module, _inputs):
            start = torch.cuda.Event(enable_timing=True)
            start.record()
            _module.__dict__["_phase_timer_start"] = (bucket, name, start)
        return _pre

    def _post(module, _inputs, _output):
        start_data = module.__dict__.pop("_phase_timer_start", None)
        if start_data is None:
            return
        bucket, name, start = start_data
        end = torch.cuda.Event(enable_timing=True)
        end.record()
        records.append((bucket, name, start, end))

    for bucket, name, mod in picks:
        handles.append(mod.register_forward_pre_hook(make_pre(bucket, name)))
        handles.append(mod.register_forward_hook(_post))

    t0 = time.perf_counter()
    with torch.inference_mode():
        if use_autocast:
            with torch.autocast(device_type="cuda", dtype=autocast_dtype):
                _ = policy.select_action(batch)
        else:
            _ = policy.select_action(batch)
    torch.cuda.synchronize(device)
    t1 = time.perf_counter()

    for h in handles:
        h.remove()

    if not records:
        return {
            "enabled": False,
            "reason": "hooks registered but no module forward events captured",
        }

    per_bucket = {"vlm": 0.0, "smolvla": 0.0}
    per_module: Dict[str, float] = {}
    for bucket, name, start, end in records:
        ms = float(start.elapsed_time(end))
        per_bucket[bucket] += ms
        per_module[name] = per_module.get(name, 0.0) + ms

    return {
        "enabled": True,
        "method": "coarse_hooks",
        "note": "approximate, may include nested overlap",
        "select_total_ms": (t1 - t0) * 1000.0,
        "smolvlm2_ms": per_bucket["vlm"],
        "smolvla_head_ms": per_bucket["smolvla"],
        "timed_modules": sorted(per_module.items(), key=lambda x: x[1], reverse=True)[:8],
    }


def parse_args() -> argparse.Namespace:
    parser = argparse.ArgumentParser(description="SmolVLA benchmark for amd64 + CUDA GPU")
    parser.add_argument("--model-path", type=Path, default=Path("./smolvla_base"), help="Local SmolVLA checkpoint dir")
    parser.add_argument("--vlm-path", type=Path, default=Path("./SmolVLM2-500M-Video-Instruct"), help="Local VLM/tokenizer dir")
    parser.add_argument("--image-path", type=Path, default=Path("./smolvla_base_test.png"), help="Input image path")
    parser.add_argument("--extra-image-paths", type=Path, nargs="*", default=[], help="额外测试图像路径，多图模式下每张图测试一次")
    parser.add_argument("--warmup", type=int, default=20, help="Warmup iterations")
    parser.add_argument("--iters", type=int, default=200, help="Benchmark iterations")
    parser.add_argument("--report-json", type=Path, default=Path("./benchmark_results/rtx4090_report.json"), help="Output benchmark report")
    parser.add_argument("--strict-arch", action="store_true", help="Fail if architecture is not amd64/x86_64")
    parser.add_argument("--gpu-id", type=int, default=0, help="CUDA GPU编号，如0/1")
    parser.add_argument("--autocast", type=str, default="fp16", choices=["none", "fp16", "bf16"], help="CUDA autocast mode")
    parser.add_argument("--load-on-cpu", action="store_true", help="先在CPU加载模型，再迁移到GPU，降低显存峰值")
    parser.add_argument("--weights-dtype", type=str, default="fp16", choices=["fp32", "fp16", "bf16"], help="模型迁移到GPU时的权重精度")
    parser.add_argument("--phase-breakdown", action="store_true", help="打印并保存 SmolVLM2 与 SmolVLA 近似分阶段耗时")
    parser.add_argument("--verify-vlm", action="store_true", help="验证SmolVLM2是否参与：参数/调用/峰值显存")
    parser.add_argument("--first-breakdown", action="store_true", help="拆分首次推理耗时(select_action/postprocess/flatten)")
    parser.add_argument("--reset-policy-each-frame", action="store_true", default=True, help="每帧推理前执行policy.reset()，避免缓存/动作队列复用")
    parser.add_argument("--no-reset-policy-each-frame", dest="reset_policy_each_frame", action="store_false", help="关闭每帧reset，允许复用策略内部状态")
    return parser.parse_args()


def dtype_from_arg(name: str) -> torch.dtype:
    if name == "fp16":
        return torch.float16
    if name == "bf16":
        return torch.bfloat16
    return torch.float32


def print_cuda_memory(tag: str, device: torch.device) -> None:
    if device.type != "cuda":
        return
    allocated = torch.cuda.memory_allocated(device) / (1024 ** 3)
    reserved = torch.cuda.memory_reserved(device) / (1024 ** 3)
    total = torch.cuda.get_device_properties(device).total_memory / (1024 ** 3)
    print(f"[显存] {tag}: allocated={allocated:.2f}GB reserved={reserved:.2f}GB total={total:.2f}GB")


def collect_vlm_param_stats(policy: Any) -> Dict[str, Any]:
    total_params = 0
    total_cuda_params = 0
    vlm_params = 0
    vlm_cuda_params = 0
    vlm_modules: List[str] = []

    for name, _module in policy.named_modules():
        if not name:
            continue
        lower = name.lower()
        if "vlm" in lower or "vision_language" in lower or "smolvlm" in lower:
            vlm_modules.append(name)

    for name, p in policy.named_parameters():
        n = int(p.numel())
        total_params += n
        if p.is_cuda:
            total_cuda_params += n

        lower = name.lower()
        if any(k in lower for k in ("vlm", "vision", "language", "text_model", "vision_model")):
            vlm_params += n
            if p.is_cuda:
                vlm_cuda_params += n

    return {
        "total_params": total_params,
        "total_cuda_params": total_cuda_params,
        "vlm_params": vlm_params,
        "vlm_cuda_params": vlm_cuda_params,
        "vlm_modules_sample": vlm_modules[:12],
    }


def verify_vlm_runtime(policy: Any, batch: Dict[str, Any], device: torch.device, use_autocast: bool, autocast_dtype: torch.dtype) -> Dict[str, Any]:
    if device.type != "cuda":
        return {"enabled": False, "reason": "requires CUDA"}

    primary = _find_primary_vlm_module(policy)
    if primary is None:
        return {"enabled": False, "reason": "no primary vlm module found"}

    module_name, module = primary
    calls = {"n": 0}
    sub_calls = {"n": 0}
    top_sub_calls: Dict[str, int] = {}

    # Best-effort reset to reduce queue/cache fast-path impact.
    if hasattr(policy, "reset") and callable(getattr(policy, "reset")):
        try:
            policy.reset()
        except Exception:
            pass

    def _pre(_m, _in):
        calls["n"] += 1

    def _sub_pre(name: str):
        def _hook(_m, _in):
            sub_calls["n"] += 1
            top_sub_calls[name] = top_sub_calls.get(name, 0) + 1
        return _hook

    handle = module.register_forward_pre_hook(_pre)
    sub_handles = []
    for child_name, child_mod in module.named_modules():
        if not child_name:
            continue
        sub_handles.append(child_mod.register_forward_pre_hook(_sub_pre(child_name)))

    torch.cuda.reset_peak_memory_stats(device)
    before_alloc = torch.cuda.memory_allocated(device)
    before_resv = torch.cuda.memory_reserved(device)

    t0 = time.perf_counter()
    with torch.inference_mode():
        if use_autocast:
            with torch.autocast(device_type="cuda", dtype=autocast_dtype):
                _ = policy.select_action(batch)
        else:
            _ = policy.select_action(batch)
    torch.cuda.synchronize(device)
    t1 = time.perf_counter()

    after_alloc = torch.cuda.memory_allocated(device)
    after_resv = torch.cuda.memory_reserved(device)
    peak_alloc = torch.cuda.max_memory_allocated(device)
    peak_resv = torch.cuda.max_memory_reserved(device)

    handle.remove()
    for h in sub_handles:
        h.remove()

    top_called = sorted(top_sub_calls.items(), key=lambda x: x[1], reverse=True)[:10]

    return {
        "enabled": True,
        "primary_vlm_module": module_name,
        "vlm_forward_calls": int(calls["n"]),
        "vlm_submodule_forward_calls": int(sub_calls["n"]),
        "vlm_top_called_submodules": top_called,
        "select_total_ms": (t1 - t0) * 1000.0,
        "memory_gb": {
            "before_allocated": before_alloc / (1024 ** 3),
            "before_reserved": before_resv / (1024 ** 3),
            "after_allocated": after_alloc / (1024 ** 3),
            "after_reserved": after_resv / (1024 ** 3),
            "peak_allocated": peak_alloc / (1024 ** 3),
            "peak_reserved": peak_resv / (1024 ** 3),
        },
    }


def count_vlm_submodule_calls_once(policy: Any, batch: Dict[str, Any], use_autocast: bool, autocast_dtype: torch.dtype) -> int:
    primary = _find_primary_vlm_module(policy)
    if primary is None:
        return -1

    _, module = primary
    sub_calls = {"n": 0}

    def _sub_pre(_m, _in):
        sub_calls["n"] += 1

    sub_handles = []
    for child_name, child_mod in module.named_modules():
        if not child_name:
            continue
        sub_handles.append(child_mod.register_forward_pre_hook(_sub_pre))

    try:
        with torch.inference_mode():
            if use_autocast:
                with torch.autocast(device_type="cuda", dtype=autocast_dtype):
                    _ = policy.select_action(batch)
            else:
                _ = policy.select_action(batch)
    finally:
        for h in sub_handles:
            h.remove()

    return int(sub_calls["n"])


def main() -> None:
    args = parse_args()

    model_path = args.model_path.resolve()
    vlm_path = args.vlm_path.resolve()
    image_path = args.image_path.resolve()
    extra_image_paths = [p.resolve() for p in args.extra_image_paths]

    if not model_path.exists():
        raise FileNotFoundError(f"Model path not found: {model_path}")
    if not vlm_path.exists():
        raise FileNotFoundError(f"VLM path not found: {vlm_path}")
    if not image_path.exists():
        raise FileNotFoundError(f"Image path not found: {image_path}")
    for p in extra_image_paths:
        if not p.exists():
            raise FileNotFoundError(f"Extra image path not found: {p}")

    print("[信息] ===== SmolVLA RTX3090 推理测试开始 =====")

    machine = platform.machine().lower()
    is_amd64 = machine in ("x86_64", "amd64")
    if args.strict_arch and not is_amd64:
        raise RuntimeError(f"Expected amd64/x86_64, got: {machine}")

    if not torch.cuda.is_available():
        raise RuntimeError("CUDA is not available. This benchmark requires a CUDA GPU.")

    gpu_count = torch.cuda.device_count()
    if args.gpu_id < 0 or args.gpu_id >= gpu_count:
        raise RuntimeError(f"无效的 --gpu-id={args.gpu_id}，当前可用GPU数量为 {gpu_count}")

    device = torch.device(f"cuda:{args.gpu_id}")
    gpu_name = torch.cuda.get_device_name(device)

    torch.backends.cudnn.benchmark = True
    torch.backends.cuda.matmul.allow_tf32 = True
    torch.backends.cudnn.allow_tf32 = True

    print(f"[信息] 机器架构: {machine} (amd64={is_amd64})")
    print(f"[信息] 使用GPU编号: {args.gpu_id} / 总GPU数: {gpu_count}")
    print(f"[信息] GPU类型: {gpu_name}")
    print(f"[信息] 模型路径: {model_path}")
    print(f"[信息] VLM路径: {vlm_path}")
    print(f"[信息] 测试图像: {image_path}")
    if extra_image_paths:
        print(f"[信息] 额外图像数量: {len(extra_image_paths)}")
        for idx, p in enumerate(extra_image_paths, start=1):
            print(f"[信息]   额外图像{idx}: {p}")
    print(f"[信息] 预热次数: {args.warmup}")
    print(f"[信息] 统计次数: {args.iters}")
    print(f"[信息] 混精模式: {args.autocast}")
    print(f"[信息] 加载策略: load_on_cpu={args.load_on_cpu} weights_dtype={args.weights_dtype}")
    print(f"[信息] 每帧强制reset: {args.reset_policy_each_frame}")
    print("[信息] 输入模态: 视觉(3路相机) + 语言(任务) + 状态(6维姿态)")

    # Force local-only loading.
    os.environ["HF_HUB_OFFLINE"] = "1"
    os.environ["TRANSFORMERS_OFFLINE"] = "1"

    config = load_json(model_path / "config.json")

    localized_model_path = create_localized_model_view(model_path, vlm_path)
    print(f"[信息] 本地化模型视图: {localized_model_path}")

    factory_mod = importlib.import_module("lerobot.policies.factory")
    smolvla_mod = importlib.import_module("lerobot.policies.smolvla.modeling_smolvla")
    make_pre_post_processors = factory_mod.make_pre_post_processors
    SmolVLAPolicy = smolvla_mod.SmolVLAPolicy

    t0_load = time.perf_counter()
    print("[信息] 正在加载 SmolVLA 模型...")
    if device.type == "cuda":
        torch.cuda.empty_cache()
        print_cuda_memory("加载前", device)

    target_dtype = dtype_from_arg(args.weights_dtype)
    try:
        with warnings.catch_warnings():
            warnings.filterwarnings("ignore", message=r".*torch_dtype.*deprecated.*")
            # 静默第三方库在加载阶段的 stdout/stderr，避免干扰测试日志。
            with contextlib.redirect_stdout(io.StringIO()), contextlib.redirect_stderr(io.StringIO()):
                if args.load_on_cpu:
                    # 先改为CPU加载，避免在GPU上直接反序列化导致峰值OOM。
                    cfg_path = localized_model_path / "config.json"
                    cfg = load_json(cfg_path)
                    cfg["device"] = "cpu"
                    with cfg_path.open("w", encoding="utf-8") as f:
                        json.dump(cfg, f, ensure_ascii=False, indent=2)

                    policy = SmolVLAPolicy.from_pretrained(str(localized_model_path)).eval()
                    policy = policy.to(device=device, dtype=target_dtype).eval()
                else:
                    policy = SmolVLAPolicy.from_pretrained(str(localized_model_path)).to(device=device, dtype=target_dtype).eval()
    except RuntimeError as exc:
        msg = str(exc).lower()
        if "out of memory" in msg or "cuda error" in msg:
            print("[错误] 模型加载发生CUDA显存不足(OOM)")
            print("[建议] 可尝试以下参数重跑:")
            print("  --load-on-cpu --weights-dtype fp16")
            print("  --autocast fp16 --warmup 5 --iters 1")
            print("[建议] 关闭占用GPU显存的其他进程后再试")
            if device.type == "cuda":
                print_cuda_memory("OOM时", device)
        raise

    t1_load = time.perf_counter()
    print(f"[时间] 模型加载耗时: {(t1_load - t0_load):.6f} 秒")
    if device.type == "cuda":
        print_cuda_memory("加载后", device)

    if args.verify_vlm:
        pstats = collect_vlm_param_stats(policy)
        print(f"[验证] 总参数量: {pstats['total_params']}")
        print(f"[验证] CUDA参数量: {pstats['total_cuda_params']}")
        print(f"[验证] VLM参数量(按名称匹配): {pstats['vlm_params']}")
        print(f"[验证] VLM CUDA参数量: {pstats['vlm_cuda_params']}")

    t0_pp = time.perf_counter()
    preprocess, postprocess = make_pre_post_processors(
        policy.config,
        str(localized_model_path),
        preprocessor_overrides={"device_processor": {"device": str(device)}},
    )
    t1_pp = time.perf_counter()
    print(f"[时间] 预处理/后处理器构建耗时: {(t1_pp - t0_pp):.6f} 秒")

    image_paths: List[Path] = []
    seen = set()
    for p in [image_path] + extra_image_paths:
        sp = str(p)
        if sp in seen:
            continue
        seen.add(sp)
        image_paths.append(p)

    # 先基于首图构建一个基准batch，用于后续可选验证功能。
    t0_pre = time.perf_counter()
    first_observation = build_observation(config, image_paths[0])
    first_batch = preprocess(dict(first_observation))
    first_batch = sanitize_batch_for_select_action(first_batch, device)
    t1_pre = time.perf_counter()
    print(f"[信息] 观测构造完成，共{len(image_paths)}张图像")
    print(f"[信息] 任务文本: Pick the red block and place it in the blue region")
    print(f"[信息] 状态维度: {tuple(torch.zeros(parse_state_dim(config), dtype=torch.float32).shape)}")
    print(f"[时间] 首图预处理耗时: {(t1_pre - t0_pre):.6f} 秒")

    use_autocast = args.autocast != "none"
    autocast_dtype = torch.float16 if args.autocast == "fp16" else torch.bfloat16

    def infer_once(batch_input: Dict[str, Any]) -> List[float]:
        if args.reset_policy_each_frame and hasattr(policy, "reset") and callable(getattr(policy, "reset")):
            policy.reset()
        with torch.inference_mode():
            if use_autocast:
                with torch.autocast(device_type="cuda", dtype=autocast_dtype):
                    out = policy.select_action(batch_input)
            else:
                out = policy.select_action(batch_input)
            try:
                out = postprocess(out)
            except Exception:
                pass
            return flatten_action_to_list(out)

    def infer_once_with_breakdown(batch_input: Dict[str, Any]) -> Tuple[List[float], Dict[str, float]]:
        breakdown: Dict[str, float] = {}

        if args.reset_policy_each_frame and hasattr(policy, "reset") and callable(getattr(policy, "reset")):
            policy.reset()

        with torch.inference_mode():
            if device.type == "cuda":
                sel_start = torch.cuda.Event(enable_timing=True)
                sel_end = torch.cuda.Event(enable_timing=True)
                if use_autocast:
                    with torch.autocast(device_type="cuda", dtype=autocast_dtype):
                        sel_start.record()
                        out = policy.select_action(batch_input)
                        sel_end.record()
                else:
                    sel_start.record()
                    out = policy.select_action(batch_input)
                    sel_end.record()
                torch.cuda.synchronize(device)
                breakdown["select_action_ms"] = float(sel_start.elapsed_time(sel_end))
            else:
                t_sel0 = time.perf_counter()
                if use_autocast:
                    with torch.autocast(device_type="cpu", dtype=autocast_dtype):
                        out = policy.select_action(batch_input)
                else:
                    out = policy.select_action(batch_input)
                t_sel1 = time.perf_counter()
                breakdown["select_action_ms"] = (t_sel1 - t_sel0) * 1000.0

            t_post0 = time.perf_counter()
            try:
                out = postprocess(out)
            except Exception:
                pass
            if device.type == "cuda":
                torch.cuda.synchronize(device)
            t_post1 = time.perf_counter()
            breakdown["postprocess_ms"] = (t_post1 - t_post0) * 1000.0

            t_flat0 = time.perf_counter()
            action_vals = flatten_action_to_list(out)
            t_flat1 = time.perf_counter()
            breakdown["flatten_ms"] = (t_flat1 - t_flat0) * 1000.0

        breakdown["inside_infer_ms"] = (
            breakdown["select_action_ms"]
            + breakdown["postprocess_ms"]
            + breakdown["flatten_ms"]
        )
        return action_vals, breakdown

    def prepare_batch_for_image(img_path: Path) -> Tuple[Dict[str, Any], float]:
        t_pre0 = time.perf_counter()
        observation = build_observation(config, img_path)
        batch_item = preprocess(dict(observation))
        batch_item = sanitize_batch_for_select_action(batch_item, device)
        t_pre1 = time.perf_counter()
        return batch_item, (t_pre1 - t_pre0) * 1000.0

    # Warmup
    if args.warmup > 0:
        print("[信息] 开始预热推理...")
    for _ in range(max(0, args.warmup)):
        _ = infer_once(first_batch)
    torch.cuda.synchronize(device)
    if args.warmup > 0:
        print("[信息] 预热完成")

    # Benchmark
    print("[信息] 开始正式计时...")
    latencies_ms: List[float] = []
    last_action: List[float] = []
    first_call_breakdown: Optional[Dict[str, float]] = None
    per_image_results: List[Dict[str, Any]] = []
    if len(image_paths) > 1:
        print("[信息] 多图模式已启用：每张图像测试一次")
        for i, img_p in enumerate(image_paths):
            batch_item, pre_ms = prepare_batch_for_image(img_p)
            t0 = time.perf_counter()
            if args.verify_vlm:
                if args.reset_policy_each_frame and hasattr(policy, "reset") and callable(getattr(policy, "reset")):
                    policy.reset()
                sub_calls = count_vlm_submodule_calls_once(
                    policy=policy,
                    batch=batch_item,
                    use_autocast=use_autocast,
                    autocast_dtype=autocast_dtype,
                )
                if device.type == "cuda":
                    torch.cuda.synchronize(device)
                action_vals = infer_once(batch_item)
                if i == 0 and args.first_breakdown:
                    # 多图+verify路径下也给首图分段，单独再测一次。
                    _a, first_call_breakdown = infer_once_with_breakdown(batch_item)
            else:
                if i == 0 and args.first_breakdown:
                    action_vals, first_call_breakdown = infer_once_with_breakdown(batch_item)
                else:
                    action_vals = infer_once(batch_item)
            torch.cuda.synchronize(device)
            t1 = time.perf_counter()
            ms = (t1 - t0) * 1000.0
            latencies_ms.append(ms)
            last_action = action_vals
            row = {
                "image_path": str(img_p),
                "preprocess_ms": pre_ms,
                "latency_ms": ms,
                "action": action_vals,
            }
            if args.verify_vlm:
                row["vlm_submodule_forward_calls"] = sub_calls
            per_image_results.append(row)
    else:
        for i in range(max(1, args.iters)):
            if i == 0:
                batch_item = first_batch
            else:
                batch_item, _ = prepare_batch_for_image(image_paths[0])
            t0 = time.perf_counter()
            if i == 0 and args.first_breakdown:
                action_vals, first_call_breakdown = infer_once_with_breakdown(batch_item)
            else:
                action_vals = infer_once(batch_item)
            torch.cuda.synchronize(device)
            t1 = time.perf_counter()
            latencies_ms.append((t1 - t0) * 1000.0)
            last_action = action_vals

    lat_sorted = sorted(latencies_ms)
    total_ms = sum(latencies_ms)
    mean_ms = statistics.fmean(latencies_ms)
    fps = (1000.0 / mean_ms) if mean_ms > 0 else 0.0
    first_call_ms = latencies_ms[0] if latencies_ms else 0.0
    steady_latencies = latencies_ms[1:] if len(latencies_ms) > 1 else []
    steady_mean_ms = statistics.fmean(steady_latencies) if steady_latencies else first_call_ms

    report = {
        "machine": machine,
        "is_amd64": is_amd64,
        "gpu_name": gpu_name,
        "model_path": str(model_path),
        "vlm_path": str(vlm_path),
        "image_path": str(image_path),
        "tested_images": [str(p) for p in image_paths],
        "load_seconds": t1_load - t0_load,
        "warmup": int(args.warmup),
        "iterations": int(len(image_paths) if len(image_paths) > 1 else args.iters),
        "autocast": args.autocast,
        "latency_ms": {
            "mean": mean_ms,
            "first_call": first_call_ms,
            "steady_mean": steady_mean_ms,
            "min": lat_sorted[0] if lat_sorted else 0.0,
            "max": lat_sorted[-1] if lat_sorted else 0.0,
            "p50": percentile(lat_sorted, 50),
            "p90": percentile(lat_sorted, 90),
            "p95": percentile(lat_sorted, 95),
            "p99": percentile(lat_sorted, 99),
            "sum": total_ms,
        },
        "throughput_fps": fps,
        "action_output": {
            "last_action": last_action,
            "action_dim": len(last_action),
        },
    }

    if args.phase_breakdown or int(args.iters) == 1:
        phase = measure_phase_breakdown(
            policy=policy,
            batch=first_batch,
            device=device,
            use_autocast=use_autocast,
            autocast_dtype=autocast_dtype,
        )
        report["phase_breakdown"] = phase

    if args.verify_vlm:
        vlm_verify = verify_vlm_runtime(
            policy=policy,
            batch=first_batch,
            device=device,
            use_autocast=use_autocast,
            autocast_dtype=autocast_dtype,
        )
        report["vlm_verification"] = vlm_verify

    if per_image_results:
        report["per_image_results"] = per_image_results

    if args.first_breakdown and first_call_breakdown is not None and latencies_ms:
        first_call_breakdown["iteration_total_ms"] = latencies_ms[0]
        report["first_call_breakdown"] = first_call_breakdown

    args.report_json.resolve().parent.mkdir(parents=True, exist_ok=True)
    with args.report_json.resolve().open("w", encoding="utf-8") as f:
        json.dump(report, f, ensure_ascii=False, indent=2)

    print("[结果] 推理测试完成")
    if latencies_ms:
        print(f"[结果] 单次推理耗时(最新一次): {latencies_ms[-1]:.3f} ms")
    if int(args.iters) == 1 and latencies_ms:
        print(f"[结果] 单次推理耗时(唯一样本): {latencies_ms[0]:.3f} ms")
    print(f"[结果] 平均推理耗时: {mean_ms:.3f} ms")
    print(f"[结果] 首次推理耗时: {first_call_ms:.3f} ms")
    print(f"[结果] 稳态推理均值(去掉首帧): {steady_mean_ms:.3f} ms")
    print(f"[结果] P95 推理耗时: {percentile(lat_sorted, 95):.3f} ms")
    print(f"[结果] 推理吞吐: {fps:.3f} FPS")
    print(f"[结果] 动作输出(Action): {last_action}")
    if per_image_results:
        print("[结果] 每张图像单次耗时:")
        for item in per_image_results:
            msg = (
                f"[结果]   {item['image_path']}: preprocess={float(item['preprocess_ms']):.3f} ms, "
                f"inference={float(item['latency_ms']):.3f} ms"
            )
            if "vlm_submodule_forward_calls" in item:
                msg += f", vlm_sub_calls={int(item['vlm_submodule_forward_calls'])}"
            print(msg)
    first_breakdown_data = report.get("first_call_breakdown")
    if isinstance(first_breakdown_data, dict):
        print("[结果] 首次推理分段耗时:")
        print(f"[结果]   模型前向(select_action): {float(first_breakdown_data.get('select_action_ms', 0.0)):.3f} ms")
        print(f"[结果]   后处理(postprocess): {float(first_breakdown_data.get('postprocess_ms', 0.0)):.3f} ms")
        print(f"[结果]   动作展平(flatten): {float(first_breakdown_data.get('flatten_ms', 0.0)):.3f} ms")
        print(f"[结果]   推理内合计(inside_infer): {float(first_breakdown_data.get('inside_infer_ms', 0.0)):.3f} ms")
        print(f"[结果]   迭代端到端总耗时: {float(first_breakdown_data.get('iteration_total_ms', 0.0)):.3f} ms")
    phase_data = report.get("phase_breakdown")
    if isinstance(phase_data, dict) and phase_data.get("enabled"):
        print(f"[结果] 分阶段耗时(近似) SmolVLM2: {phase_data.get('smolvlm2_ms', 0.0):.3f} ms")
        print(f"[结果] 分阶段耗时(近似) SmolVLA头: {phase_data.get('smolvla_head_ms', 0.0):.3f} ms")
        print(f"[结果] select_action总耗时(近似): {phase_data.get('select_total_ms', 0.0):.3f} ms")
        if phase_data.get("method"):
            print(f"[结果] 分阶段计时方法: {phase_data.get('method')}")
    elif isinstance(phase_data, dict):
        print(f"[结果] 分阶段耗时不可用: {phase_data.get('reason', 'unknown')} ")

    vlm_verify_data = report.get("vlm_verification")
    if isinstance(vlm_verify_data, dict):
        if vlm_verify_data.get("enabled"):
            print(f"[验证] VLM前向调用次数: {vlm_verify_data.get('vlm_forward_calls')} (模块: {vlm_verify_data.get('primary_vlm_module')})")
            print(f"[验证] VLM子模块前向调用总数: {vlm_verify_data.get('vlm_submodule_forward_calls', 0)}")
            mem = vlm_verify_data.get("memory_gb", {})
            print(f"[验证] 单次推理峰值显存(allocated): {float(mem.get('peak_allocated', 0.0)):.3f} GB")
            print(f"[验证] 单次推理峰值显存(reserved): {float(mem.get('peak_reserved', 0.0)):.3f} GB")
        else:
            print(f"[验证] VLM运行验证不可用: {vlm_verify_data.get('reason', 'unknown')} ")
    print(json.dumps(report, ensure_ascii=False, indent=2))
    print(f"[结果] 报告文件: {args.report_json.resolve()}")
    print("[信息] ===== SmolVLA RTX3090 推理测试结束 =====")


if __name__ == "__main__":
    main()
